Introduction
As underground construction season winds down across Western Canada, project teams are focused on completing service entrances, secondary distribution systems, and medium-voltage feeders before winter conditions arrive.
From residential developments and commercial projects to municipal and utility infrastructure, underground cable selection remains a critical part of keeping projects on schedule. Prysmian's USEI90, USEB90, and Concentric Neutral MV cable solutions support a wide range of underground power distribution applications.
Understanding Underground Distribution Applications
Service entrance and underground distribution cables often serve similar applications, but differences in neutral construction, voltage requirements, and utility specifications can influence product selection.
The following overview highlights where each cable is commonly used and the key characteristics that distinguish it.
| Service entrance cable requirements vary by utility territory, municipality, and project specification. Always verify local utility requirements before cable selection. |
SERVICE ENTRANCES (600V)
USEI90 Cable (600V)
Insulated Neutral Conductor
Ideal for: Service entrances, residential, developments, and underground secondary distribution.
✅Includes one insulated neutral conductor.
✅Remaining conductors are insulated phase conductors.
✅Direct burial rated.
✅Available in 3C and 4C constructions.
✅XLPE Insulation with PVC jacket.
EXPLORE USEI90 CABLES
USEB90 Cable (600V)
Bare Copper Concentric Neutral
Ideal for: Service entrances, residential, developments, and underground secondary distribution.
✅Bare copper concentric neutral.
✅Direct burial rated.
✅Available with full or reduced neutral.
✅XLPE Insulation with PVC jacket.
EXPLORE USEB90 CABLES
MEDIUM VOLTAGE FEEDERS (5kV - 35kV)
Concentric Neutral MV Cable
Medium-Voltage Distribution Cable
Ideal for: Utility distribution, municipal infrastructure, commercial development, and industrial power distribution.
✅Concentric neutral for grounding and fault return capability.
✅Direct burial rated.
✅Available in 5kV - 35kV.
✅TR-XLPE or EPR insulation with LLDPE or PVC jacket.
EXPLORE CONCENTRIC NEUTRAL MV CABLES
Beat the Freeze. Finish Strong.
As construction season winds down, reliable access to the right cable can make the difference between keeping a project on schedule and waiting until spring.
From service entrances to medium-voltage feeders, USEI90, USEB90, and Concentric Neutral MV cables support a wide range of underground distribution applications. Backed by local inventory, technical expertise, and project support, Texcan and Prysmian are ready to help keep your underground projects moving before winter arrives.
