50-3073f-040aia
BELDEN CANADA INC - CND$ 123073F J22 DataTray Twin Coaxial Cable Aluminum Interlock Armor 18 AWG 100 O Blue
50-3073f-040aia
BELDEN CANADA INC - CND$ 123073F J22 DataTray Twin Coaxial Cable Aluminum Interlock Armor 18 AWG 100 O Blue
Description
Coax, Twinaxial, 18 AWG, 600V, 1 Conductor, Tinned copper (7 x 26) conductor, Polyolefin, Combination, 1st shield-100% Tape, 2nd shield 55% Tinned Copper braid, PVC, AIA, CSA, FT4, Blue
Specifications
| Armoured | Yes | Shield | Combination |
| AWG Size | 18 | # of Pairs | 1 |
| Flame Test Rating | Yes | Cable Type | Coax |
| Approximate Diameter (in.) | 0.71 | Color | Blue |
| Conductor Material | Tinned copper (7 x 26) conductor | CSA | Yes |
| Insulation Material | Polyolefin | Name | Belden Coax Cable Twinaxial 600V 1 Conductor 18 AWG Blue |
| Net Weight KG/ KM | 344 | Net Weight LB/MFT | 231 |
| # of Shields | 2 | Options | Multiple construction and colors available upon request |
| Shield 1 Coverage | 100% | Shield 1 Material | Aluminum Foil Shield |
| Shield 2 Coverage | 55% | Shield 2 Material | Tinned Copper Braid |
| Shield Material | 1st shield-100% Tape, 2nd shield 55% Tinned Copper braid | Voltage | 600V |
