50-6541ue
BELDEN CANADA INC - CND$ 6541UE Multi-Conductor Cable Shielded, Sound 4 Conductors Flamarrest PVC Jacket
50-6541ue
BELDEN CANADA INC - CND$ 6541UE Multi-Conductor Cable Shielded, Sound 4 Conductors Flamarrest PVC Jacket
ManufacturerBELDEN CANADA INC - CND$
ManufacturerProductNumber:6541UE
Description
Multi-Pair, 22 AWG, 300V, 2 Pairs, Stranded (7 x 30) BC - Bare Copper, LS PVC - Low Smoke Polyvinyl Chloride, Unshielded, LS PVC, CSA, FT4, Natural
Specifications
| Armoured | No | Shield | Unshielded |
| AWG Size | 22 | # of Pairs | 2 |
| Flame Test Rating | Yes | Cable Type | Multi-Pair |
| Approximate Diameter (in.) | 0.199 | Color | Natural |
| Conductor Material | Stranded (7X30) BC - Bare Copper | CSA | Yes |
| Name | Belden Multi-Pair Cable 300V 2 Pairs 22 AWG Natural | Net Weight KG/ KM | 27 |
| Net Weight LB/MFT | 18 | Options | Multiple construction and colors available upon request |
| Voltage | 300V |
