50-8241a
BELDEN CANADA INC - CND$ 8241A COAXIAL RG 59/U PE/PVC 95%
50-8241a
BELDEN CANADA INC - CND$ 8241A COAXIAL RG 59/U PE/PVC 95%
ManufacturerBELDEN CANADA INC - CND$
ManufacturerProductNumber:8241A
Description
Coax, RG59U, 23 AWG, 30V, 1 Conductor, Solid BCCS - Bare Copper Covered Steel, FR Semi-Foam PE - Flame Retardant Semi-Foam Polyethylene, Overall Shield, TC - Tinned Copper 95% Braid, PVC, CSA, FT4, Black
Specifications
| Armoured | No | Shield | Overall Shield |
| AWG Size | 23 | No of Conductors | 1 |
| Flame Test Rating | Yes | Cable Type | Coax |
| Approximate Diameter (in.) | 0.242 | Color | Black |
| Conductor Material | Solid BCCS - Bare Copper Covered Steel | CSA | Yes |
| Jacket Material | Polyvinyl Chloride (PVC) | Name | Belden Coax Cable RG59/U 30V 1 Conductor 23 AWG Black |
| Net Weight KG/ KM | 58 | Net Weight LB/MFT | 39 |
| # of Shields | 1 | Options | Multiple construction and colors available upon request |
| Shield 1 Coverage | 95% | Shield 1 Material | Tinned Copper Braid |
| Shield Material | TC - Tinned Copper 95% Braid | Voltage | 30V |
