Multi-Conductor, 18 AWG, 300V, 9 Conductors, Stranded (19X30) TC - Tinned Copper, PVC - Polyvinyl Chloride, Unshielded, PVC, CSA, FT4, Grey
50-8469
BELDEN CANADA INC - CND$ 8469 Multi-Conductor Cable Electronic, Shielded 9 Conductors PVC Jacket Gray
Description
Specifications
| Armoured | No | Shield | Unshielded |
| AWG Size | 18 | No of Conductors | 9 |
| Flame Test Rating | Yes | Cable Type | Multi-Conductor |
| Approximate Diameter (in.) | 0.364 | Color | Grey |
| Conductor Material | Stranded (19X30) TC - Tinned Copper | CSA | Yes |
| Name | Belden Multi-Conductor Cable 300V 9 Conductors 18 AWG Grey | Net Weight KG/ KM | 143 |
| Net Weight LB/MFT | 96 | Options | Multiple construction and colors available upon request |
| Voltage | 300V |
