50-88760
High Temperature Electronic Pair, Shielded 2 Conductors Fluorinated Ethylene Propylene Jacket
50-88760
High Temperature Electronic Pair, Shielded 2 Conductors Fluorinated Ethylene Propylene Jacket
ManufacturerBELDEN CANADA INC - CND$
ManufacturerProductNumber:88760
Description
Pair, 18 AWG, 300V, 1 Pair, Stranded (19X30) TC - Tinned Copper, FEP - Fluorinated Ethylene Propylene, Tape Aluminum Foil-PolYester100%-Spiral, FEP, CSA, FT6, Red
Specifications
| Armoured | No | Shield | Overall Shield |
| AWG Size | 18 | # of Pairs | 1 |
| Flame Test Rating | Yes | Cable Type | Pair |
| Approximate Diameter (in.) | 0.15 | Color | Red |
| Conductor Material | Stranded (19X30) TC - Tinned Copper | CSA | Yes |
| Insulation Material | Fluorinated Ethylene Propylene (FEP) | Jacket Material | Fluorinated Ethylene Propylene (FEP) |
| Name | Belden Multi-Pair Cable 300V 1 Pair 18 AWG Red | Net Weight KG/ KM | 36 |
| Net Weight LB/MFT | 24 | # of Shields | 1 |
| Options | Multiple construction and colors available upon request | Shield 1 Coverage | 100% |
| Shield 1 Material | Aluminum Foil Shield | Shield Material | Tape Aluminum Foil-PolYester100% |
| Voltage | 300V |
