50-9451-090
BELDEN CANADA INC - CND$ 9451 F/SHLD 1PR-22 STC PPL/PVC GREY
50-9451-090
BELDEN CANADA INC - CND$ 9451 F/SHLD 1PR-22 STC PPL/PVC GREY
ManufacturerBELDEN CANADA INC - CND$
ManufacturerProductNumber:9451
Description
Pair, 22 AWG, 300V, 1 Pair, Stranded (7x30 ) TC - Tinned Copper, PP - Polypropylene, Tape Aluminum Foil-PolYester100%-Spiral, PVC, CSA, FT4, Grey
Specifications
| Armoured | No | Shield | Overall Shield |
| AWG Size | 22 | # of Pairs | 1 |
| Flame Test Rating | Yes | Cable Type | Pair |
| Approximate Diameter (in.) | 0.135 | Color | Grey |
| Conductor Material | Stranded (7x30 ) TC - Tinned Copper | CSA | Yes |
| Name | Belden Multi-Pair Cable 300V 1 Pair 22 AWG Grey Stranded | Net Weight KG/ KM | 21 |
| Net Weight LB/MFT | 14 | # of Shields | 1 |
| Options | Multiple construction and colors available upon request | Shield 1 Coverage | 100% |
| Shield 1 Material | Aluminum Foil Shield | Shield Material | Tape Aluminum Foil-PolYester100% |
| Voltage | 300V |
