50-9418
BELDEN CANADA INC - CND$ 9418 Multi-Conductor Cable Electronic 4 Conductors PVC Jacket
50-9418
BELDEN CANADA INC - CND$ 9418 Multi-Conductor Cable Electronic 4 Conductors PVC Jacket
ManufacturerBELDEN CANADA INC - CND$
ManufacturerProductNumber:9418
Description
Multi-Conductor, 18 AWG, 300V, 4 Conductors, Stranded (19X30) TC - Tinned Copper, S-R PVC - Semi-Rigid Polyvinyl Chloride, Overall Shield, Tape Aluminum Foil-PolYester100%, PVC, CSA, FT4, Grey
Specifications
| Armoured | No | Shield | Overall Shield |
| AWG Size | 18 | No of Conductors | 4 |
| Flame Test Rating | Yes | Cable Type | Multi-Conductor |
| Approximate Diameter (in.) | 0.245 | Color | Grey |
| Conductor Material | Stranded (19X30) TC - Tinned Copper | CSA | Yes |
| Name | Belden Multi-Conductor Cable 300V 4 Conductors 18 AWG Grey | Net Weight KG/ KM | 71 |
| Net Weight LB/MFT | 48 | # of Shields | 1 |
| Options | Multiple construction and colors available upon request | Shield 1 Coverage | 100% |
| Shield 1 Material | Aluminum Foil Shield | Shield Material | Tape Aluminum Foil-PolYester100% |
| Voltage | 300V |
