50-9775-090aia
BELDEN CANADA INC - CND$ 129775 F/SHLD 9PR-18 STC SP AIA GREY
50-9775-090aia
BELDEN CANADA INC - CND$ 129775 F/SHLD 9PR-18 STC SP AIA GREY
ManufacturerBELDEN CANADA INC - CND$
ManufacturerProductNumber:129775
Description
Multi-Pair, 18 AWG, 300V, 9 Pairs, Stranded (19x30) TC - Tinned Copper, Polypropylene, Individually Shield, Individually Aluminum foil shield pairs, PVC, AIA, CSA, FT4, Grey
Specifications
| Armoured | Yes | Shield | Individually Shield |
| AWG Size | 18 | # of Pairs | 9 |
| Flame Test Rating | Yes | Cable Type | Multi-Pair |
| Approximate Diameter (in.) | 0.965 | Color | Grey |
| Conductor Material | Stranded (19X30) TC - Tinned Copper | CSA | Yes |
| Name | Belden Multi-Pair Cable 300V 9 Pairs 18 AWG Grey | Net Weight KG/ KM | 649 |
| Net Weight LB/MFT | 436 | # of Shields | 2 |
| Options | Multiple construction and colors available upon request | Shield 1 Coverage | 100% |
| Shield 1 Material | Aluminum Foil Shield | Shield 2 Coverage | 100% |
| Shield 2 Material | Aluminum Foil Shield | Shield Material | Individually Aluminum foil shield pairs |
| Voltage | 300V |
