50-9729
BELDEN CANADA INC - CND$ 9729 Overall Beldfoil® Multi-Conductor Cable Low Capacitance 24 AWG 2 Pair Conductors Tinned Copper Chrome
50-9729
BELDEN CANADA INC - CND$ 9729 Overall Beldfoil® Multi-Conductor Cable Low Capacitance 24 AWG 2 Pair Conductors Tinned Copper Chrome
Description
Multi-Pair, 24 AWG, 300V, 2 Pairs, Stranded (7x32 ) TC - Tinned Copper, FPE - Foam Polyethylene, Individually Shield, Tape Aluminum Foil-PolYester100%, PVC, CSA, Grey
Specifications
| Armoured | No | Shield | Individually Shield |
| AWG Size | 24 | # of Pairs | 2 |
| Flame Test Rating | No | Cable Type | Multi-Pair |
| Approximate Diameter (in.) | 0.266 | Color | Grey |
| Conductor Material | Stranded (7x32 ) TC - Tinned Copper | CSA | Yes |
| Name | Belden Multi-Pair Cable 300V 2 Pairs 24 AWG Grey | Net Weight KG/ KM | 52 |
| Net Weight LB/MFT | 35 | # of Shields | 2 |
| Options | Multiple construction and colors available upon request | Shield 1 Coverage | 100% |
| Shield 1 Material | Aluminum Foil Shield | Shield 2 Coverage | 100% |
| Shield 2 Material | Aluminum Foil Shield | Shield Material | Tape Aluminum Foil-PolYester100% |
| Voltage | 300V | UPC | 612825257547 |
