52-159-0314-010
COAX RG 59/U W/ 18-2C SHLD FT4
52-159-0314-010
COAX RG 59/U W/ 18-2C SHLD FT4
Description
Coax, Composite, RG59, 20 AWG, 150V, 1 Conductor, 20 awg 1c Sol bare copper c/w 18 awg str 2c black & red, Foam polyethylene (FPE) on coax, 1pr, Overall, 95% Bare copper braid, PVC, FT4, CSA, Black
Specifications
| Armoured | No | Shield | Overall |
| AWG Size | 20 | No of Conductors | 1 |
| # of Pairs | 1 | Flame Test Rating | Yes |
| Cable Type | Coax | Approximate Diameter (in.) | 0.232 x 0.421 |
| Conductor Material | 20 awg 1c Sol bare copper c/w 18 awg str 2c black & red | CSA | Yes |
| Insulation Material | Foam Polyethylene (FPE) on Coax, PVC Insulation 1pr | Jacket Material | Polyvinyl Chloride (PVC) |
| Name | Coax Cable RG59 150V 1 Conductor 20 AWG Black | Net Weight KG/ KM | 97 |
| Net Weight LB/MFT | 65 | # of Shields | 1 |
| Options | Other coloured outer jacket and constructions available upon request , Stranded bare copper conductors | Shield 1 Coverage | 0.95 |
| Shield 1 Material | Bare Copper Braid | Shield Material | 1st shield - 95% Bare copper braid |
| Voltage | 150 |
