52-725105/60-020
COAX RG6/U FPE/PVC 60% FT6 WHT
52-725105/60-020
COAX RG6/U FPE/PVC 60% FT6 WHT
Description
Coax, RG6, 18 AWG, 300V, 1 Conductor, Solid bare copperweld, Foamed-FEP, Combination, 1st shield-100% Tape, 2nd shield 60% Aluminum braid, Polymer, FT6, CSA, White
Specifications
| Armoured | No | Shield | Combination |
| AWG Size | 18 | No of Conductors | 1 |
| Flame Test Rating | Yes | Cable Type | Coax |
| Approximate Diameter (in.) | 0.25 | Conductor Material | Solid Bare Copperweld |
| CSA | Yes | Jacket Material | Polymer |
| Name | Coax Cable RG6 300V 1 Conductor 18 AWG White | Net Weight KG/ KM | 48 |
| Net Weight LB/MFT | 32 | # of Shields | 2 |
| Options | Other coloured outer jacket and constructions available upon request , Stranded bare copper conductors | Shield 1 Coverage | 1 |
| Shield 1 Material | Aluminum Foil Shield | Shield 2 Coverage | 0.6 |
| Shield 2 Material | Aluminum Braid | Shield Material | 1st shield - 100% Tape, 2nd shield 60% Aluminum braid |
| Voltage | 300 |
