19014-01-012

Teck Cable 6 AWG 8kV 3C Shielded 140 Mil. 133%

Length

Description

Teck Cable, 8kV, 3 Conductor, 6 AWG, Stranded Bare Copper, TR-XLPE, 140 Mil., 133%, Shielded, PVC, AIA, CSA, FT4

Specifications

Armoured Yes Voltage 8kV
AWG Size 6 No of Conductors 3
Insulation Material Tree-Retardant Cross-Linked Polyethylene (TR-XLPE) CSA Yes
Approximate Diameter Armour 1.645 Approximate Diameter Inner Jacket (in.) 1.405
Approximate Diameter Outer Jacket (in.) 1.755 Armour Material Aluminum Interlocked Armour (AIA)
Color Black Conductor Material Stranded bare copper
Copper Content KG/KM 600 Copper Content LB/MFT 403
Flame Test Rating Yes Approximate Diameter Insul. (in.) 0.495
Jacket Material Polyvinyl Chloride (PVC) Name Teck Cable 6 AWG 8kV 3C Shielded 140 Mil. 133%
Options Galvanized Steel Interlocked Armour (GSIA). Other coloured outer jacket and constructions available upon request. Helically applied 20% overlapped copper tape shield
